USB-485/2, USB-485/2 bộ chuyển đổi cổng kết nối RS422, RS485

Nhà sản xuất: NI

Danh mục: Thiết bị thu thập dữ liệu NI

Thiết bị giao diện nối tiếp 4 cổng, USB, RS485/RS422 Giao diện USB‑485/4 chuyển đổi cổng USB của bạn thành một cổng nối tiếp không đồng bộ duy nhất để giao tiếp với các thiết bị RS485 và RS422. Bạn có thể sử dụng cổng USB‑485/4 làm cổng nối tiếp chuẩn từ ứng dụng của mình, bao gồm các đường bắt tay phần cứng RTS/CTS. Giao diện nối tiếp NI cũng xuất hiện dưới dạng cổng COM chuẩn để tương thích với các chương trình sử dụng giao tiếp nối tiếp.

NATIONAL INSTRUMENTS ( ni)

USB-232 / USB-485 Series Serial Instrument Control Interfaces

MODEL:

USB‑485/2 (2-Port)

USB‑485/4 (4-Port)

The National Instruments USB-232 / USB-485 Series Serial Instrument Control Interfaces for USB transform the user’s Universal Serial Bus (USB) port into asynchronous serial ports for communication with serial devices. The NI USB-232 and USB-485 are available in either 1, 2, or 4-port versions and use standard RS-232, RS-422, or RS-485 communications. All products include driver software for Windows 2000/XP. One can install and use the USB-232 and USB-485 as standard serial ports from your existing applications or with applications written with NI-VISA.

4-Port, USB, RS485/RS422 Serial Interface Device
The USB‑485/4 interface transforms your USB port into a single asynchronous serial port for communication with RS485 and RS422 devices. You can use a USB‑485/4 port as a standard serial port from your application, including RTS/CTS hardware handshake lines. NI serial interfaces also appear as standard COM ports for compatibility with programs that use serial communications.

Part Number(s): 778476-74 | 778476-64 | 778476-54 | 778476-44 | 778476-34 | 778476-24 | 778476-14 | 778476-104 | 778476-94

Features:

Compatible with Standard PC Serial Port
1, 2, and 4-Port Versions
Handle RTS/CTS Hardware Handshake Lines
128 B Transmit and Receive FIFOs
5,6,7, or 8 Data Bits

Additionally, the USB-232 2 and 4-port versions feature software-selectable DTE or DCE transceiver modes, as well as an automatic transceiver detection mode, or Auto232. The USB-485 features software selectable biasing; therefore, you can turn biasing on and off for each port through software.

Development environments, such as Visual Basic, Visual C++, and Excel, as well as National Instruments LabVIEW, LabWindows/CVI and Measurement Studio, can access the serial ports using standard serial I/O functions.
